KEY FEATURES
- Simple to set up and cost effective
- Compatible with IEC 60687, EC 61036, IEC 61268, IEC 62053-21, IEC 62053-22, and IEC 62053-23 standards
- Hot swap redundancy exchange and fail safe ready
- Stand-alone programming or Modular operation modes
- The device supports Over the Air (OTA) programming through mobile application
- Active energy error percentage does not exceed 0.1% at 25°C
- Provides several power consumptions values such as active, reactive and apparent energy, voltage RMS, current RMS
- Digital power, phase, and RMS offset calibration programmable thresholds for line voltage SAG and overvoltage detections
- 32-bit ARM core microcontroller with 48 MHz clock
- 1x Ethernet 10/100 port
- 1x RS485 port
- 2x Relay output
- High resolution 0.91” OLED display
- Wide range of power supply options (10-60 VDC)
- Highly compacted size
- Simple to set up and cost effective
- Standard din rail mounting option
- -40 to 85 °C Operating temperature
- 5% to 90% Non-condensing Relative Humidity
Out of stock
