PMM0628XT

12 x Isolated Digital Inputs / 6 x Isolated Transistor Digital Outputs

KEY FEATURES

  • 12 Isolated digital inputs
  • 6 Isolated transistor digital outputs
  • Standard Modbus RTU communication over RS-485
  • Designed for digital input monitoring, transistor output control, and automation applications
  • 32-bit ARM core microcontroller with 48 MHz clock
  • Stand-alone operation or modular expansion capability
  • Isolated RS-485 communication interface
  • USB service port for configuration and maintenance
  • Wide input power supply range (12 - 48 VDC)
  • Overvoltage and reverse polarity protection
  • Reliable industrial-grade design with surge protection
  • EMI, EMS, EMC, and shock resistant
  • Standard 35 mm DIN rail mounting
  • Operating temperature: -40 to 80 °C (-40 to 185 °F)
  • 5% to 90% non-condensing relative humidity
6 in stock
Base Price: 54$

Contact Sales

DESCRIPTION

PMM0628XT is a combined digital input and transistor output module designed for industrial automation, remote monitoring, and control applications. The module provides twelve isolated digital inputs and six isolated transistor digital outputs that can be monitored and controlled through standard Modbus RTU communication over an RS-485 interface.

Designed for reliable operation in harsh industrial environments, PMM0628XT combines isolated field interfaces, industrial-grade protection circuits, and a wide DC power input range. The module can be integrated into SCADA systems, PLC networks, renewable energy plants, substations, and other automation systems requiring dependable digital status acquisition and transistor output control.

Its compact DIN-rail mounting design, simple configuration process, and robust communication interface make PMM0628XT an ideal solution for monitoring field contacts, interlocks, alarms, and control feedback while also driving external relays, indicators, signaling devices, and other low-power DC loads.

APPLICATIONS

PMM0628XT is suitable for a wide range of industrial and utility automation applications, including:

  • SCADA and remote terminal unit (RTU) systems
  • Substation automation and interlocking systems
  • Solar and renewable energy plant monitoring and control
  • Digital input status monitoring and alarm collection
  • Transistor output control
  • Industrial process automation
  • Building management and utility control systems
  • General-purpose digital I/O expansion
