PMM - Power Meter Monitor


BACnet - Modbus Protocol Gateway

PMM-da-720-series-image-1-(1).jpg | PMM


  • Protocol conversion between Modbus RTU/ASCII/TCP and BACnet/IP
  • Supports Modbus RTU/ASCII/TCP master/client
  • Supports BACnet/IP server
  • Connects up to 62 Modbus RTU/ASCII slaves
  • Connects up to 32 Modbus TCP servers
  • Easy and smooth configuration via web-based server
  • Embedded traffic monitoring as well as diagnostic information for fast trouble shooting
  • Optional 1 or 2 Ethernet 10/100 ports
  • Optional supports 2.4/5 GHz WIFI
  • Optional 2x customized Fiber optic ports
  • 2 or 4 RS485 - RS232 Serial communication ports (Customizable)
  • Baud rate: 110-256000 bps
  • Operating temperature: -40 to 75°C (-40 to 167°F)
  • Storage temperature: -40 to 85°C (-40 to 185°F)
  • Ambient relative humidity 5 to 95% (non-condensing)
  • EMI, EMS, EMC and shock protected
  • Enclosure Ingress Protection Code: IP54
1 in stock
Base Price:505 $
Contact Sales


PMM0408 is a highly configurable industrial Ethernet gateway device which is capable of performing protocol conversion between Modbus RTU/ASCII/TCP and BACnet/IP.

PMM0408 provides the flexibility needed to fulfill the various conditions that arise with field devices that use different communication protocols to connect to the SCADA system.

PMM0408 gateways support a system log that main function is to record events so it can be easily monitored; users can easily review log data remotely through the web interface. The gateways also support status monitoring and fault protection functions. The status monitoring function notifies the SCADA system when a device gets disconnected or does not respond or faces any error or failures, in such cases the SCADA system gets alarms of the status of each end device to the operators to make corrective actions immediately.
